■ Kaladex
Kaladex is DuPont's trademark for its range of biaxially oriented polyethylene naphthalate (PEN) films.
With its distinct polymer chemistry this new product range has been developed specifically to meet your need for cost-effective films with a performance between polyethylene terephthalate (PET) films and polyimides.
Kaladex PEN films offer you, New and expanded market opportunities, Reduced manufacturing costs, Reduced material costs.
Kaladex PEN films are particularly suited to a wide range of applications in areas such as;
- Electrical insulation, "F Class" material
- Labels
- Electronic applications such as flexible printed circuits, membrane touch switches, flexible heaters etc.
- General industrial and graphics applications such as belts, diaphragms, transfer tapes etc.
- Packaging
Grade
Properties
Thickness
KX 1000
A clear film for use where optical transparency is of paramount importance.
75mic. to 125mic.
KX 1030/1031
A clear film with an adhesion promoting pretreatment on both sides.
KX 2000
A slightly hazy film with excellent handling properties.
25mic. to 125mic.
KX 2030
A slightly hazy film with an adhesion promoting pretreatment on both sides.
■ Teonex
These films are designed for special situations, where films are subject to especially stringent conditions such as extreme heat or harsh chemicals, or for those applications where exceptional barrier performance is required.
Type
Properties
Thickness
Q51
A slightly hazy film with excellent handling properties.
12mic. to 250mic.
Q71
A slightly hazy Ultra Thin film which were developed for capacitor applications.
1.9, 2.1 mic.
Q72
A slightly hazy Ultra Thin film which were developed for capacitor applications.
3.5mic.
Q83
A slightly hazy film with excellent handling properties with high dimensional stability.
25mic. to 75mic.
